58641-1

TE Connectivity / AMP Brand

Crimp Tool - Ratchet - AMPMODU 26 to 22AWG MOD IV Contacts - Te Connectivity / Amp 586. ...

Datasheet

RoHS Non-Compliant

Pack Packaging

Certificate of Compliance Guarantee

DESCRIPTION

The 58641-1 from TE Connectivity / AMP Brand is a PRO-CRIMPER-III hand Crimp Tool for use with AMPMODU 26 to 22AWG MOD IV contacts. It features a tool frame with a stationary jaw and handle, a moving jaw, a moving handle and an adjustable ratchet that ensures full contact crimping, the tool frame holds a die assembly with two crimping sections, die assembly features a wire anvil, an insulation anvil, a wire crimper and an insulation crimper, attached to the outside of the frame is a locator assembly which contains a locator, a spring retainer and a contact support, die retaining pins and die retaining screws are used to position and secure the dies in the tool frame, a nut is used on the upper die retaining screw to hold the locator assembly in place. This tool is intended for occasional use and low volume applications.

Product Highlights:

Potential Applications:

Search Keywords: 586411

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

58641-1

RoHS:

HTS:

8205595560

COO:

ECCN:

EAR99

Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
