583861-7 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

583861-7

10 POS. TWIN LEAF 100 C/L ...

View Datasheet Ask the Datasheet
RoHS Compliant
BOX Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

583861-7 is a crimp snap twin leaf connector housing with mounting ears designed for high-density wire-to-board applications. This connector features 13 dual positions with key dimensions including A: 1.200 in (30.48 mm), B: 1.400 in (35.56 mm), C: 1.600 in (40.64 mm), D: 1.575 in (40.01 mm), and E: 1.830 in (46.48 mm). The housing is constructed from natural nylon material and is compatible with snap-in contacts in various configurations including crimp, post, eyelet, and solder types. This connector is ideal for wire-to-board interconnect applications requiring reliable connections and easy contact insertion, with contacts available in reel-fed strip form for automatic machine application or loose piece for hand tool termination.

Product Highlights:

  • Housing
  • 10 Dual Positions
  • 2.54 mm Centerline
  • With Mounting Ears

Search Keywords: 5838617

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
583861-7
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538906000
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
400
Package Type:
BOX
Mounting:
Panel Mount
Body Orientation:
Straight
Gender:
RCP
Number of Contacts:
20
Maximum Current Rating:
5/Contact A
Operating Temperature:
-55 to 105 °C

FREQUENTLY ASKED QUESTIONS

Is 583861-7 RoHS compliant?

Yes, 583861-7 is RoHS compliant.

What is the lead time for 583861-7?

The standard lead time for 583861-7 is approximately 14 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 1,093

Can Ship immediately

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 400

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
5
$40.24
100
$40.14
250
$40.04
400
$39.93
800
$20.40
1,200
$13.88
1,600 +
$13.61
