5748472-1 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

5748472-1

KIT,PLUG,78P,HDP-22,SHLD HDWRE ...

View Datasheet Ask the Datasheet
RoHS Compliant
Pack Packaging
Accessories
Request Programming Quote
Discontinued
Certificate of Compliance

DESCRIPTION

5748472-1 is an HDP-22 crimp snap-in contact connector plug assembly designed for D-subminiature applications requiring shielding and cable strain relief. This connector features 78 contact positions (Shell Size 5) and accommodates recommended cable outer diameters ranging from 0.338 to 0.490 inches, with a maximum inner cable bundle diameter of 0.450 inches after jacket and braid removal. The connector shell is constructed of steel with tin plating, the insert is 94V-0 rated thermoplastic in black, and the shield is steel with tin plating; jackscrews are zinc alloy. The assembly includes a PVC black enclosure and is supplied unassembled and bulk-packaged in quantities of 100 pieces. This connector is ideal for industrial machinery, medical instrumentation, computers, storage systems, and on-machine industrial communications where reliable shielded connections and compact form factors are essential.

Product Highlights:

  • Connector Kit
  • Product Series = HDP-22 (Crimp Snap)
  • Number of Positions = 78
  • Shielded
  • Plug

Search Keywords: 57484721

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5748472-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538908180
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Package Type:
Pack
Type:
High Density D-Sub
Body Orientation:
Straight
Mounting:
Cable Mount
Gender:
Pin
Termination Method:
Crimp
Shell Size:
5
Number of Contacts:
78
Life Cycle:
Discontinued

FREQUENTLY ASKED QUESTIONS

Is 5748472-1 discontinued?

Yes, 5748472-1 from Te Connectivity / Amp Brand is discontinued. Master Electronics is an authorized distributor and may have remaining stock or a recommended replacement for it.

Is 5748472-1 RoHS compliant?

Yes, 5748472-1 is RoHS compliant.

What is the lead time for 5748472-1?

The standard lead time for 5748472-1 is approximately 13 weeks. In-stock quantities ship from Master Electronics.

  This product is discontinued, but still in stock

IN STOCK: 434

Can Ship immediately

Minimum Order Quantity: 5

Price (USD)

Qty
Unit Price
5
$10.80
25
$9.79
50
$9.35
100
$9.07
250
$8.58
500
$8.35
1,000 +
$8.23
