5747844-5 by te connectivity / amp brand

5747844-5

TE Connectivity / AMP Brand

D Sub Connector - DB9 - 9 Contacts - Receptacle - Solder - DE - AMPLIMITE HD-20 Series - Metal Body. ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 5747844-5 is AMPLIMITE HD-20 series Solder-cup D-sub Connectors with phosphor bronze duplex plated contacts with gold flash on mating end, tin on solder cup with entire contact nickel under-plated, thermoplastic inserts and steel, tin or zinc plated shell.

Product Highlights:

  • Number of Positions = 9
  • Receptacle
  • PCB Mount Angle = Right Angle
  • Product Series = HD 20
  • With Mating Connector Lock

Search Keywords: 57478445

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5747844-5
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
130
Package Type:
Tray
Type:
D-Subminiature
Body Orientation:
Right Angle
Mounting:
Through Hole
Gender:
SKT
Termination Method:
Solder
Shell Size:
1
Number of Contacts:
9
Contact Plating:
Gold over Nickel
Operating Temperature:
N/A

IN STOCK: 6,033

Can Ship immediately

Minimum Order: 10

Factory Lead-Time 16 Weeks

Qty
Unit Price
10
$3.52
50
$2.73
130
$2.63
260
$2.49
520
$2.48
1,040
$2.46
2,600
$2.40
5,070 +
$2.38
Suppliers Standard Package
Log in for special pricing
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Product Changes

Accessories

1571650-5

LF PLUG KIT,SIZE 1,9.5MM

2-745492-0

PLUG ASSY,9P,HDE,MS

1-747944-6

KIT,PLUG,9P,HDE,SHLD ENCLSRE

1571650-6

LF PLUG KIT,SIZE 1,10.8MM

1571650-4

LF PLUG KIT,SIZE 1,7.2MM

5747840-2

HD-20 PLUG RA .318 FMS BD-LK

5747840-3

D Sub Connector - DB9 - Size 1 - 9 Contacts - Plug - Through Hole - Right Angle - Front Me ...

5747840-4

9 Position D-Sub Plug, Male Pins Connector

5747840-5

D Sub Connector - DB9 - 9 Contacts - Plug - Through Hole - DE - AMPLIMITE HD-20 Series - S ...

Show 7 More
