5747091-2 by te connectivity / amp brand

5747091-2

TE Connectivity / AMP Brand

09 RCPT ACT PIN/MS MED SCRLK ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / AMP Brand part 5747091-2 is an electrical component designed for use in a variety of applications. This particular part is a 09 RCPT ACT PIN/MS MED SCRLK, which means it is a receptacle connector with active pins and a medium screw lock. It is commonly used in industrial, automotive, and telecommunications systems to provide secure and reliable electrical connections. With its compact design and sturdy construction, this part is engineered for durability and optimal performance.

Product Highlights:

  • Number of Positions = 9
  • Receptacle
  • PCB Mount Angle = Vertical
  • Product Series = HD 20
  • With Mating Connector Lock

Search Keywords: 57470912

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5747091-2
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
130
Package Type:
Tray
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
SKT
Termination Method:
Solder
Shell Size:
1
Number of Contacts:
9
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C

IN STOCK: 823

Ships today, if you order in

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 163

Factory Lead-Time 8 Weeks

Qty
Unit Price
5
$33.36
50
$32.86
100
$32.37
163
$31.88
325
$16.88
488
$11.60
650 +
$11.36
Log in for special pricing
Please Note: Tariffs may apply for U.S. shipments
