5227673-1 by te connectivity / amp brand

5227673-1

TE Connectivity / AMP Brand

RF / Coaxial Connector - BNC Coaxial - Straight Jack - Solder - 50 ohm - Phosphor Bronze. ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 5227673-1 is a through-hole BNC Straight Jack for use with printed circuit board (PCB). It has nickel-plated zinc body with gold-plated phosphor bronze centre contact and a polymethylpentene insulator.

Product Highlights:

  • Connector
  • Connector Type = BNC
  • Jack
  • Terminate To Printed Circuit Board
  • PCB Mount Angle = Vertical

Search Keywords: 52276731

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5227673-1
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
35
Package Type:
Tube
Type:
BNC
Impedance:
50 Ohm
Operating Frequency:
0 to 4 Hz to GHz
Gender:
RCP
Mounting:
Through Hole
Body Orientation:
Straight
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-55 to 85 °C
Dimension:
14.76 x 15.88 x 35.57 mm
  Possible Replacement options available.  See Alternatives

IN STOCK: 4

Can Ship immediately

You may purchase all in-stock quantity of 4

On Order: 945   can ship 12/17/25

Minimum Order: 35

Available in less than min: 4

Multiple: 35

Factory Lead-Time 16 Weeks

Qty
Unit Price
1
$3.19
35
$2.90
70
$2.83
280
$2.59
525
$2.57
1,015
$2.51
2,520
$2.16
5,005 +
$2.15
Suppliers Standard Package
