5103310-2 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

5103310-2

A/L LOW PRO HDR 14P RA BLACK ...

View Datasheet Ask the Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

5103310-2 is a low-profile right-angle PCB mount pin header designed for ribbon cable interconnection applications. It features 14 positions with 0.100 inch [2.54 mm] centerline spacing and 0.025 inch [0.64 mm] square posts at the mating end. The header has a post plating finish (Plating B designation) and is configured for manual insertion into PCB holes with recommended hole layout dimensions of 1.000 inch [25.40 mm] length (A) and 0.600 inch [15.24 mm] width (B). This connector is RoHS compliant and is commonly used in ribbon cable interconnect solutions for low-profile applications requiring reliable mechanical and electrical connections in compact spaces.

Product Highlights:

  • Connector Type = Pin Headers
  • Low Profile
  • Number of Positions = 14
  • 2.54 x 2.54 mm Centerline, Matrix
  • PCB Mount Angle = Right Angle

Search Keywords: 51033102

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5103310-2
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
TUBE
Type:
Shrouded Header
Body Orientation:
Right Angle
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
14
Maximum Voltage Rating:
N/A
Maximum Current Rating:
1/Contact A
Termination Method:
Solder
Operating Temperature:
-65 to 105 °C

FREQUENTLY ASKED QUESTIONS

Is 5103310-2 RoHS compliant?

Yes, 5103310-2 is RoHS compliant.

What is the lead time for 5103310-2?

The standard lead time for 5103310-2 is approximately 11 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 2,594

Can Ship immediately

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 11 Weeks

Price (USD)

Qty
Unit Price
100
$1.18
300
$1.15
500
$1.14
1,000
$1.11
2,500
$1.10
5,000
$1.09
7,500 +
$1.08
Supplier's Standard Package
