5-103168-8 by te connectivity / amp brand
Image is representational - see mfr. specs

5-103168-8

TE Connectivity / AMP Brand

A 20-position, double-row, shrouded vertical header with straight posts on a .100 x .100 inch centerline for board-to-board connections. ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 5-103168-8 is a 20-position, double-row, shrouded vertical header from the AMPMODU Interconnection System. It features .025 inch square straight posts arranged in a .100 x .100 inch grid. The copper alloy contacts have duplex plating with .000030 inches of gold on the contact area and tin on the solder tails, all over a nickel underplate. Housed in a black, 94V-0 rated flame-retardant thermoplastic with detent windows, this header ensures secure and reliable mating. It is designed for board-to-board applications such as mother/daughter board connections and other subassembly interconnections.

Product Highlights:

  • Header
  • Header Type = Shrouded
  • Number of Rows = Dual
  • Number of Positions = 20
  • Mating Post Length = 8.08 mm

Search Keywords: 51031688

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
5-103168-8
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
176
Package Type:
Tray
Type:
Shrouded Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
20
Maximum Voltage Rating:
N/A
Maximum Current Rating:
3/Contact A
Termination Method:
Solder
Operating Temperature:
-55 to 105 °C

IN STOCK: 2,788

Can Ship immediately

Minimum Order Quantity: 10

Factory Lead-Time 21 Weeks

Qty
Unit Price
10
$4.07
50
$3.73
176
$3.46
352
$3.32
528
$3.23
1,056
$3.09
2,640
$2.47
5,104 +
$2.28
Suppliers Standard Package
