350825-1 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

350825-1

03P UMNL HDR ASSY PC 94VO ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

350825-1 is a 3-circuit vertical socket header designed for use with Universal MATE-N-LOK connectors. This PCB header features a pre-tin finish and standard tail configuration suitable for 0.062 inch (1.57 mm) thick PC boards. The header has an A dimension of 0.800 inches (20.32 mm) and is rated UL94V-0 for flammability. It mates with plug housing part numbers 770018-1 (Universal MATE-N-LOK II) and 350766-1 (Universal MATE-N-LOK). This connector is ideal for wire-to-board applications in home appliances and power circuit connections requiring reliable, secure mating.

Product Highlights:

  • Header
  • Universal MATE-N-LOK, Universal MATE-N-LOK II
  • Not CompactPCI
  • 6.35 mm Centerline, Matrix
  • Number of Circuits = 3

Search Keywords: 3508251

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
350825-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
BAG
Type:
Power
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
SKT
Number of Contacts:
3
Termination Method:
Solder
Maximum Voltage Rating:
600 VAC
Maximum Current Rating:
19/Contact A
Operating Temperature:
N/A

FREQUENTLY ASKED QUESTIONS

Is 350825-1 RoHS compliant?

Yes, 350825-1 is RoHS compliant.

What is the lead time for 350825-1?

The standard lead time for 350825-1 is approximately 13 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 3,510

Can Ship immediately

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 13 Weeks

Price (USD)

Qty
Unit Price
100
$0.5507
300
$0.5274
1,000
$0.5024
2,500
$0.4927
5,000
$0.4915
7,500
$0.4902
10,000
$0.4890
15,000 +
$0.4878
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Accessories

350848-3

03P UMNL PLUG TEST ASSY 94VO

770018-1

3 Position Rectangular Housing Connector Plug White 0.250" (6.35mm)

350766-1

This housing from TE comes from their Wire to Board Universal MATE-N-LOK Connectors series ...

Show 1 More
