325150 by te connectivity / amp brand
Image is representational - see mfr. specs

325150

TE Connectivity / AMP Brand

The 325150 is a Pre-Insulated Diamond Grip (PIDG) flanged spade tongue terminal for terminating 12-10 AWG wire. ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 325150 is a PIDG (Pre-Insulated Diamond Grip) spade tongue terminal designed for reliable wire termination. It features a closed barrel design, accepts a wire size range of 12-10 AWG, and is suitable for a #6 or M3.5 stud. The terminal is constructed from tin-plated copper with yellow nylon insulation, providing support and protection for the connection. Rated for a maximum of 300 VAC, it can accommodate a maximum insulation diameter of 6.35 mm. The straight, flanged spade tongue shape ensures a secure connection, making it suitable for various industrial and commercial electrical applications.

Product Highlights:

  • Terminal Shape = Spade Tongue, Flanged
  • Receptacle Style = Straight
  • Body Style = PIDG
  • Barrel Type = Closed Barrel
  • Wire/Cable Type = Regular Wire

Search Keywords: 325150

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
325150
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Package Type:
Box

IN STOCK: 95

Can Ship immediately

On Order: 12   can ship 11/23/26

Minimum Order Quantity: 50

Factory Lead-Time 30 Weeks

Qty
Unit Price
1
$1.87
50
$1.70
250
$1.63
500
$1.37
1,000
$1.34
2,500
$1.08
5,000 +
$1.04
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Accessories

59239-4

Hand Crimper Tool - Manual - Splices and Terminals - 10-12 AWG and 14-16 AWG HD - Ratchet ...

58433-3

Crimp Tool: PRO-CRIMPER III Mnl Crimp Tool Frame (354940-1) + Die Set for PIDG, PLASTI-GRI ...

58423-1

Tool Die Set For Splices and Terminals - 10 to 22 AWG.

169404

CERTI-LOK DIE

Show 2 More
