32510 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

32510

TERMINAL,PIDG SPD FLG 12-10 8 ...

View Datasheet Ask the Datasheet
RoHS Compliant
BOX Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 32510 is an AMP PIDG spade terminal designed for electrical connections in wire sizes 4.0–6.0 mm² (AWG 12–10). It features a tin-plated copper terminal material with a nylon insulation sleeve, providing corrosion resistance and reliable electrical contact. The terminal is configured with an M4.0 bolt connection and a 4.3 mm stud hole, with dimensions of 10.7 mm width, 6.3 mm contact length, and a maximum length of 25.4 mm. The insulation diameter accommodates up to 5.8 mm, and the terminal thickness is 1.0 mm. This spade terminal is commonly used in automotive, industrial, and power distribution applications where secure, high-current connections are required, offering excellent mechanical strength and electrical performance for heavy-gauge wire terminations.

Product Highlights:

  • Terminal Shape = Spade Tongue, Flanged
  • Receptacle Style = Straight
  • Body Style = PIDG
  • Barrel Type = Closed Barrel
  • Wire/Cable Type = Regular Wire

Search Keywords: 32510

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
32510
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Package Type:
BOX

FREQUENTLY ASKED QUESTIONS

Is 32510 RoHS compliant?

Yes, 32510 is RoHS compliant.

What is the lead time for 32510?

The standard lead time for 32510 is approximately 30 days. In-stock quantities ship from Master Electronics.

IN STOCK: 2,168

Ships today, if you order in

Minimum Order Quantity: 500

Multiple: 500

Factory Lead-Time 30 Weeks

Price (USD)

Qty
Unit Price
500
$0.6161
1,000
$0.5885
2,500
$0.5554
5,000
$0.5402
7,500
$0.5258
10,000
$0.4995
15,000
$0.4929
25,000 +
$0.4540
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Accessories

59239-4

Hand Crimper Tool - Manual - Splices and Terminals - 10-12 AWG and 14-16 AWG HD - Ratchet ...

59824-1

Crimp Tool - Hand - AMP TETRA PIDG/PLASTI-GRIP/PIDG Faston 22-10AWG Terminals & Splices.

58423-1

Tool Die Set For Splices and Terminals - 10 to 22 AWG.

169404

CERTI-LOK DIE

58433-3

Crimp Tool: PRO-CRIMPER III Mnl Crimp Tool Frame (354940-1) + Die Set for PIDG, PLASTI-GRI ...

Show 3 More
