320627

TERMINAL,PIDG R 16-14HD 8 ...

View Datasheet Ask the Datasheet
RoHS Compliant
BOX Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

320627 is a pre-insulated diamond grip (PIDG) ring tongue terminal designed for secure electrical connections. This heavy-duty terminal features a closed barrel construction with nylon insulation and accommodates 16-14 AWG wire (1.25-2.00 mm²). The copper terminal with tin finish is rated for 30 VAC and fits stud size 8 (M4) with a stud diameter of 4.17 mm. The yellow/black color-coded insulation supports a maximum insulation diameter of 5.84 mm, and the tongue material thickness is 1.27 mm for extra mechanical strength. This terminal is ideal for applications requiring reliable, insulated wire-to-stud connections in electrical assemblies.

Product Highlights:

  • Terminal Shape = Ring Tongue
  • Receptacle Style = Straight
  • Body Style = PIDG
  • Barrel Type = Closed Barrel
  • Wire/Cable Type = Regular Wire

Search Keywords: 320627

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
320627
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Package Type:
BOX

FREQUENTLY ASKED QUESTIONS

Is 320627 RoHS compliant?

Yes, 320627 is RoHS compliant.

What is the lead time for 320627?

The standard lead time for 320627 is approximately 32 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 7,197

Can Ship immediately

MOQ for In Stock Qty: 50

MOQ for out of Stock Qty: 1250

Factory Lead-Time 32 Weeks
