3-1827231-6 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

3-1827231-6

.5FHR04H,440,B,GIG,08/Sn,HT,NS ...

View Datasheet Ask the Datasheet
RoHS Compliant
TRAY Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

3-1827231-6 is a fine pitch SMT stacking receptacle connector designed for parallel board-to-board applications. This 440-position connector features a 0.5mm pitch with a 4mm height and bridge (B) type configuration, incorporating ground contacts (G-Con) for enhanced signal integrity. Key dimensions include A: 54.50mm (2.146"), B: 61.80mm (2.433"), C: 3.25mm (0.128"), D: 62.80mm (2.472"), E: 6.20mm (0.244"), and F: 6.00mm (0.236"). The connector is rated for an operating temperature range of -40°C to +85°C, with a current rating of 0.5A, voltage rating of 50 VAC, and durability of 30 mating cycles. It is supplied in hard tray packaging with pickup cap and is RoHS compliant, making it suitable for computer, telecommunications, and industrial applications.

Product Highlights:

  • Receptacle
  • Family Name = Free Height
  • .50 mm Centerline
  • Number of Positions = 440
  • In-Line Contact Layout

Search Keywords: 318272316

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
3-1827231-6
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
18
Package Type:
TRAY
Type:
Fine Pitch Connector
Body Orientation:
Straight
Gender:
RCP
Mounting:
Surface Mount
Pitch:
0.5 mm
Number of Contacts:
440
Maximum Voltage Rating:
50 VAC
Maximum Current Rating:
0.5/Contact A
Termination Method:
Solder
Operating Temperature:
-40 to 85 °C

FREQUENTLY ASKED QUESTIONS

Is 3-1827231-6 RoHS compliant?

Yes, 3-1827231-6 is RoHS compliant.

What is the lead time for 3-1827231-6?

The standard lead time for 3-1827231-6 is approximately 17 days. In-stock quantities ship from Master Electronics.

IN STOCK: 4,298

Ships today, if you order in

MOQ for out of Stock Qty: 297

Factory Lead-Time 17 Weeks

Price (USD)

Qty
Unit Price
1
$34.92
50
$29.01
100
$28.72
297
$28.37
594
$28.09
891
$27.81
1,188 +
$27.53
Log in for special pricing Click for Quote Price Match Request
