280422-2

TE Connectivity / AMP Brand

The 280422-2 is an AMPMODU MOD II series receptacle contact supplied in a strip for Crimp-On, Snap-In (COSI) termination. ...

Datasheet
RoHS Compliant
Reel Packaging
Accessories
Request Programming Quote
Discontinued
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 280422-2 is an AMPMODU MOD II receptacle contact designed for Crimp-On, Snap-In (COSI) applications. Supplied in a strip format, it is suitable for automated termination processes. This contact is intended for crimp termination and is noted as not being applicable for solder process capability. The component is compliant with EU RoHS and ELV directives and is classified as low-halogen. As part of the AMPMODU MOD II interconnect system, these contacts are used to create reliable connections in various electronic devices.

Product Highlights:

  • Contact
  • Contact Type = Receptacle
  • Terminate To Wire
  • Wire Insulation Diameter = 1.75 mm
  • Wire Range = 0.05-0.09² [30-28] mm [AWG]

Search Keywords: 2804222

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
280422-2
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
PL
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
20000
Package Type:
Reel
Connector System:
Wire-to-Board
Circuit Application:
Signal
Termination Method to Wire & Cable:
Crimp
Contact Type:
Socket
Packaging Method:
Reel
Connector Mounting Type:
Cable Mount (Free-Hanging)
Contact Base Material:
Phosphor Bronze
Contact Mating Area Plating Material Thickness:
15 µin
Wire Insulation Support:
With
Compatible With Wire & Cable Type:
Discrete Wire
Contact Mating Area Plating Material:
Gold
Contact Current Rating (Max):
3 A
Wire Contact Termination Area Plating Material:
Gold Flash
Packaging Quantity:
20000
Applied Pressure:
Standard
Operating Temperature Range:
-40 – 80 °C, -40 – 176 °F
Mating Square Post Dimension:
.025 in, .64 mm
Wire Size:
30 – 28 AWG, 100.5 – 159.8 CMA, .05 – .09 mm²
Connector & Contact Terminates To:
Wire & Cable
Life Cycle:
Discontinued
  This product is discontinued, but still in stock

IN STOCK: 9,200

Can Ship immediately

Minimum Order Quantity: 100

Qty
Unit Price
100
$0.2868
2,500
$0.1893
5,000
$0.1833
7,500
$0.1758
10,000
$0.1740
20,000
$0.1723
30,000
$0.1714
40,000 +
$0.1705
Reel Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Product Changes

Accessories

58654-1

PRO-CRIMP TL & DIE MOD II

58654-2

PRO-CRIMPER DIE SET ONLY
