2-5747706-0 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

2-5747706-0

9 Position D-Sub Receptacle, Female Sockets Connector ...

View Datasheet Ask the Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 2-5747706-0 is a 9-way 2-row front metal-shell D-sub Receptacle with gold-plated phosphor bronze contacts and retention 4-40 brass inserts. The Amplimite HD-20 series straight posted receptacle comes with black thermoplastic housing, tin-plated carbon steel shell and bright tin-plated solder tail. All receptacles are preloaded with size 20 DF posted socket contacts. Connectors are intermateable with any size 20 subminiature D connectors dimensionally complying with MIL-C-24308. UL94V-0 Flammability rating Vertical PCB mounting orientation Applications Industrial, Computers & Computer Peripherals

Product Highlights:

  • Number of Positions = 9
  • Receptacle
  • PCB Mount Angle = Vertical
  • Product Series = HD 20
  • Without Mating Connector Lock

Search Keywords: 257477060

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
2-5747706-0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
17
Package Type:
TUBE
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
SKT
Termination Method:
Solder
Shell Size:
1
Number of Contacts:
9
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C

FREQUENTLY ASKED QUESTIONS

Is 2-5747706-0 RoHS compliant?

Yes, 2-5747706-0 is RoHS compliant.

What is the lead time for 2-5747706-0?

The standard lead time for 2-5747706-0 is approximately 40 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 0

On Order: 1,054   can ship 3/1/27

Minimum Order Quantity: 17

Multiple: 17

Factory Lead-Time 40 Weeks

Price (USD)

Qty
Unit Price
17
$6.16
51
$5.97
102
$5.70
255
$5.46
510
$5.23
1,003
$5.09
2,516
$4.34
5,015 +
$3.92
Supplier's Standard Package
