2-1761608-3 by te connectivity / amp brand

2-1761608-3

TE Connectivity / AMP Brand

Connector Header Through Hole 10 position 0.100" (2.54mm) ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

TE Connectivity AMP-LATCH connectors are wire-to-board devices used to make the transition between cable and PC board circuitry. The mass termination capabilities of the AMP-LATCH family of connectors have made ribbon cable popular within the Electronics Industry. The ability to terminate up to 64 conductors simultaneously, without stripping or otherwise preparing the cable, saves labor. The AMP-LATCH Line is available on three separate cable centerline spacings including .050 [1.27], .039 [1.00], and .025 [0.64]. Applications include computers/electronics, business equipment, and medical equipment. Contact Shape Square Contact Finish - Mating Gold or Gold-Palladium Contact Finish Thickness - Mating 30.0µin (0.76µm) Contact Finish - Post Tin Contact Material Phosphor Bronze Insulation Material Polybutylene Terephthalate (PBT) Features Keying Slot Operating Temperature -65°C ~ 105°C

Product Highlights:

  • Connector Type = Pin Header
  • Low Profile
  • Number of Positions = 10
  • 2.54 x 2.54 mm Centerline, Matrix
  • PCB Mount Angle = Vertical

Search Keywords: 217616083

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
2-1761608-3
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
26
Package Type:
Tube
Type:
Ejector Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
10
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
1/Contact A
Termination Method:
Solder
Operating Temperature:
-65 to 105 °C

IN STOCK: 21

Can Ship immediately

You may purchase all in-stock quantity of 21

On Order: 1,170   can ship 1/7/26

Minimum Order: 26

Available in less than min: 21

Multiple: 26

Factory Lead-Time 13 Weeks

Qty
Unit Price
1
$3.377
26
$3.070
104
$3.030
260
$3.020
520
$3.000
1,014
$2.990
2,522 +
$2.970
