1-87499-2

Name: 1-87499-2 Te Connectivity Amp Brand Discrete Wire Housing
Brand: Te Connectivity Amp Brand
SKU: 10195705
Availability: InStock

06 MODIV HSG COMP SR .100CL ...

View Datasheet

Ask the Datasheet

RoHS Compliant

BAG Packaging

Certificate of Compliance

DESCRIPTION

The 1-87499-2 is a single-row receptacle housing assembly part of the AMPMODU Mod IV Interconnection System, designed for wire-to-board connections with dual entry and end-stackable configuration. The housing features a 0.100 inch by 0.100 inch [2.54 x 2.54 mm] centerline spacing with low-profile design and 0.200 inch [5.08 mm] tine spacing, constructed from glass-filled thermoplastic material rated 94V-0. The contact area includes localized gold plating with duplex plating options (Plating A, B, or C) on matte tin solder areas, all over 0.00127 inch [0.00127 mm] nickel, and the assembly is RoHS compliant. This receptacle housing is suitable for applications requiring reliable multi-position interconnections in compact, stackable configurations, with contact current ratings of 3 amperes and termination resistance of 12 milliohms maximum for beryllium copper contacts.

Product Highlights:

Connector
Without Contacts
Housing Gender = Connector - Receptacle
Housing Accepts Contact Type = Receptacle
2.54 mm Centerline

Potential Applications:

Search Keywords: 1874992

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

1-87499-2

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8538906000

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
