180351-1 by te connectivity / amp brand
Image is representational - see mfr. specs

180351-1

TE Connectivity / AMP Brand

Quick Disconnect - Female - 0.250" (6.35mm) Tab Width - 0.032" (0.81mm) Tab Thickness - 10 to 12 AWG - Non-Insulated - Crimp Termination. ...

Datasheet
RoHS Compliant
Reel Packaging
Accessories
Request Programming Quote
Discontinued
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 180351-1 from TE Connectivity / AMP Brand is female quick disconnect with 0.250" (6.35mm) tab width, 0.032" (0.81mm) tab thickness and crimp termination. This is unplated brass quick disconnect for wires range from 10 to 12 AWG. Operating temperature range is from -40 to 110 °C ( -40 to 230 °F ).

Product Highlights:

  • Receptacle
  • Tab Fit = 6.35 x 0.81 mm
  • Wire Range = 3.00-6.00² [12-10] mm [AWG]
  • Insulation Diameter = 3.43-5.08 [.135-.200] mm [in]
  • Receptacle Style = Straight

Search Keywords: 1803511

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
180351-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
IT
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
3000
Package Type:
Reel
Barrel Type:
Open
Accepts Wire Insulation Diameter Range:
.134 – .2 in, 3.4 – 5.1 mm
Life Cycle:
Discontinued
  This product is discontinued, but still in stock

IN STOCK: 403,361

Can Ship immediately

Minimum Order Quantity: 822

Qty
Unit Price
822
$0.096
4,106
$0.091
16,421
$0.087
41,051
$0.084
123,153 +
$0.080
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Accessories

1-1579007-4

Extraction Tool for Standard & Junior TIMER; FASTIN-FASTON & POSITIVE-LOK Tab 2.8, 4.8, 5. ...

4-1579007-3

Extraction Tool for Standard TIMER etc. Kit comprises: 1-1579007-4 & 1-1579007-6
