1-794617-0 by te connectivity / amp brand

1-794617-0

TE Connectivity / AMP Brand

Connector Housing - Micro MATE-N-LOK Series - Receptacle - 10 Ways - 3 mm - Micro MATE-N-LOK Connectors. ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 1-794617-0 is a 10-position 2-row black Receptacle Housing, made of nylon 66/6 and is used with micro MATE-N-LOK connectors. The connectors with dual locking lances provide optimum contact stability pins and sockets can be intermixed in the same housing.

Product Highlights:

  • Housing
  • Housing Type = Receptacle
  • Number of Positions = 10
  • Number of Rows = Dual
  • 3.00 mm Centerline

Search Keywords: 17946170

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-794617-0
Alias/AKA:
BACA-AMP-136
RoHS:
Yes
HTS:
8538906000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Mounting:
Cable Mount
Body Orientation:
Straight
Gender:
RCP
Number of Contacts:
10
Maximum Voltage Rating:
250,250 VDC|VAC
Maximum Current Rating:
5/Contact A
Operating Temperature:
-40 to 105 °C

IN STOCK: 24,352

Can Ship immediately

Manufacturer Stock: 132,000   can ship 12/1/25

Minimum Order: 50

Factory Lead-Time 17 Weeks can ship 3/18/26

Qty
Unit Price
50
$0.4363
500
$0.2577
1,000
$0.2549
2,500
$0.2536
5,000
$0.2524
7,500
$0.2511
10,000
$0.2498
15,000 +
$0.2486
Log in for special pricing
Please Note: Tariffs may apply for U.S. shipments
