1-770166-0 by te connectivity / amp brand

1-770166-0

TE Connectivity / AMP Brand

The new TE lance-less terminals have replaced the original design with a stamped-out window on the terminal underside. The new feature slides over a locking tab in the housing cavity and produces an audible click to ensure the terminal is fully seated. The contacts are secured by a secondary locking device by inserting a TPA retainer. This is a recently added feature that includes 12-position breakaway style contact retainers that prevent the contacts from backing out due to random vibration. ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / AMP Brand part 1-770166-0 is a revolutionary and upgraded version of the original design. It features a stamped-out window on the terminal underside, completely eliminating the need for lances. This new design ensures a more secure and reliable connection, as the terminal slides over a locking tab within the housing cavity and produces an audible click, confirming that the terminal is fully seated.To further enhance the reliability of the connection, the contacts are secured by a secondary locking device. This is achieved by inserting a TPA retainer, which serves as a safeguard against the contacts backing out due to random vibrations. The TPA retainer is a recently added feature, and with the inclusion of 12-position breakaway style contact retainers, it provides exceptional stability and prevents any unwanted disconnections.Overall, the TE Connectivity / AMP Brand part 1-770166-0 sets a new standard in terminal design, delivering superior performance, heightened security, and enhanced durability. Trust in this advanced solution to ensure optimal connectivity in your applications.

Product Highlights:

  • Header
  • Mini-Universal MATE-N-LOK, Mini-Universal MATE-N-LOK 2
  • Number of Circuits = 2
  • 4.14 mm Centerline, Matrix
  • In-Line Contact Layout

Search Keywords: 17701660

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-770166-0
RoHS:
Yes
HTS:
8536694040
COO:
US
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Package Type:
Bag
Type:
Power
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
HDR
Number of Contacts:
2
Termination Method:
Solder
Maximum Voltage Rating:
600 VAC
Maximum Current Rating:
9.5/Contact A
Operating Temperature:
N/A

IN STOCK: 17,913

Ships today, if you order in

Minimum Order: 200

Multiple: 200

Factory Lead-Time 4 Weeks

Qty
Unit Price
200
$0.5820
400
$0.5500
1,000
$0.5280
2,600
$0.5070
5,000
$0.4995
7,600
$0.4970
10,000
$0.4945
15,000 +
$0.4920
Suppliers Standard Package
