1-640508-0 by te connectivity / amp brand

1-640508-0

TE Connectivity / AMP Brand

Connector Housing - MR Series - Receptacle - 3 Positions - 4.19 mm - Miniature Rectangular Connectors. ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 1-640508-0 is a 3-position 1-row Wire-to-Panel/Wire-to-Wire Miniature Rectangular Connector with tin-plated contacts and UL94V-0 brick red nylon housing. Housings positively lock to help prevent accidental disengagement. Either cap or plug housing can be mounted in same rectangular panel cut-out without additional hardware. Plug and cap design includes moulded-in polarizing feature for proper mating. Numbered cavities for easy circuit identification. Egg crate design of plug half fully encloses socket contacts, reducing shock hazard. Moulded skirt extension on cap protects pin contacts. Strain reliefs for 6 through 36 positions are available. Socket solder tail contacts available for hot side PC board mounting. High density achieved through 4.19mm contact centreline spacing. Contacts accept 26 to 18AWG (0.12 to 0.8 mm²) wire sizes and insulation diameters of 0.635 to 2.92mm.

Product Highlights:

  • Housing
  • Number of Circuits = 3
  • 4.19 mm Centerline, Matrix
  • In-Line Contact Layout
  • Housing Type = Receptacle (Cap)

Search Keywords: 16405080

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-640508-0
RoHS:
Yes
HTS:
8538906000
COO:
US
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Mounting:
Cable Mount
Body Orientation:
Straight
Gender:
RCP
Number of Contacts:
3
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
9/Contact A
Operating Temperature:
-55 to 85 °C

IN STOCK: 17,594

Can Ship immediately

Manufacturer Stock: 8,306   can ship 12/1/25

Minimum Order: 10

Factory Lead-Time 18 Weeks can ship 3/25/26

Qty
Unit Price
10
$1.65
100
$1.17
250
$1.13
500
$1.09
1,000
$1.05
2,500
$1.04
5,000 +
$1.03
Log in for special pricing
