1586041-8 by te connectivity / amp brand

1586041-8

TE Connectivity / AMP Brand

8P VAL-U-LOK R/A HDR V2 ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 1586041-8 is an 8P VAL-U-LOK right angle header connector from TE Connectivity's AMP Brand. With a compact design, this connector provides a secure and reliable connection, making it ideal for various electrical applications. The V2 version offers improved performance and durability. Perfect for cramped spaces and tight angles, this connector ensures efficient and space-saving wire-to-board connections.

Product Highlights:

  • Pin Header
  • Number of Circuits = 8
  • UL 94V-2
  • Number of Rows = Dual
  • Right Angle Mount Angle

Search Keywords: 15860418

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1586041-8
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
210
Package Type:
Tray
Type:
Power
Body Orientation:
Right Angle
Mounting:
Through Hole
Gender:
Pin
Number of Contacts:
8
Termination Method:
Solder
Maximum Voltage Rating:
600 VAC
Maximum Current Rating:
9/Contact A
Operating Temperature:
-40 to 105 °C

IN STOCK: 141

Can Ship immediately

You may purchase in-stock quantity up to 141

On Order: 5,040   can ship 11/24/25

Minimum Order: 210

Available in less than min: 141

Multiple: 210

Factory Lead-Time 16 Weeks

Qty
Unit Price
1
$0.5510
210
$0.5010
420
$0.4931
1,050
$0.4732
2,520
$0.4634
5,040
$0.4585
7,560
$0.4562
10,080
$0.4539
15,120 +
$0.4517
Suppliers Standard Package
Log in for special pricing
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Product Changes

Accessories

794954-8

8P RCPT VAL-U-LOK V2

106527-8

Conn Housing RCP 8 POS 4.2mm Crimp ST Cable Mount Package
