1-5747150-6 by te connectivity / amp brand

1-5747150-6

TE Connectivity / AMP Brand

D Sub Connector - DB9 - 9 Contacts - Receptacle - Solder - DE - AMPLIMITE HD-20 Series - Metal Body. ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 1-5747150-6 is AMPLIMITE HD-20 series Solder-cup D-sub Connectors with phosphor bronze duplex plated contacts with gold flash on mating end, tin on solder cup with entire contact nickel under-plated, thermoplastic inserts and steel, tin or zinc plated shell.

Product Highlights:

  • Number of Positions = 9
  • Receptacle
  • PCB Mount Angle = Vertical
  • Product Series = HD 20
  • With Mating Connector Lock

Search Keywords: 157471506

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-5747150-6
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
17
Package Type:
Tube
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
SKT
Termination Method:
Solder
Shell Size:
1
Number of Contacts:
9
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C

IN STOCK: 1,354

Ships today, if you order in

Minimum Order: 17

Multiple: 17

Factory Lead-Time 11 Weeks

Qty
Unit Price
17
$4.23
51
$4.16
102
$4.03
255
$3.95
510
$3.93
1,003
$3.91
2,516
$3.89
5,015 +
$3.87
Suppliers Standard Package
Log in for special pricing
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Product Changes

Accessories

747515-7

09 HDE PMOLD PLUG, LEAD FREE

5746862-4

9 POS HDF PLUG, MS

1-745492-9

PLUG ASSY,9P,HDE,MS

1658613-4

09 POS HDF PLUG, MS, LEAD FREE

1658608-4

09 POS HDF PLUG, MS, LEAD FREE

1-745492-7

09 HDE MS PLUG,26-30,LEAD FREE

1-745492-8

D Sub Connector - DB9 - 9 Contacts - Plug - IDC / IDT - DE - Amplimite HDE-20 Series - Ste ...

1-747944-5

09 SHLDG ENCL PLUG,LEAD FREE

Show 6 More
