1-5747150-3 by te connectivity / amp brand

1-5747150-3

TE Connectivity / AMP Brand

9 Position D-Sub Receptacle, Female Sockets Connector ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

TE Connectivity, the industry leader in AMPLIMITE D-Subminiature solutions, provides a complete range of quality, time-tested D-sub connectors that have become the standard in the D-Sub industry. TE Connectivity's complete line of D-Subminiature Connectors range from right-angle and vertical-posted connectors and cable connectors to the AMPLIMITE .050 Series D-Sub connectors. Connector Style D-Sub Connector Type Receptacle, Female Sockets Number of Positions 9 Number of Rows 2 Shell Size, Connector Layout 1 (DE, E) Contact Type Signal Mounting Type Through Hole Flange Feature Mating Side, Female Screwlock (4-40) Termination Solder Shell Material, Finish Steel, Tin Plated Contact Finish Gold Contact Finish Thickness Flash Material Flammability Rating UL94 V-0 Current Rating (Amps) 6A Operating Temperature -55°C ~ 105°C Voltage Rating 125V Color Black

Product Highlights:

  • Number of Positions = 9
  • Receptacle
  • PCB Mount Angle = Vertical
  • Product Series = HD 20
  • With Mating Connector Lock

Search Keywords: 157471503

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-5747150-3
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
17
Package Type:
Tube
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
SKT
Termination Method:
Solder
Shell Size:
1
Number of Contacts:
9
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C

IN STOCK: 248

Ships today, if you order in

On Order: 1,071   can ship 11/26/25

Minimum Order: 17

Multiple: 17

Factory Lead-Time 20 Weeks

Qty
Unit Price
17
$3.98
51
$3.88
102
$3.77
255
$3.68
510
$3.63
1,003
$3.61
2,516
$3.59
5,015 +
$3.58
Suppliers Standard Package
Log in for special pricing
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Accessories

1571650-5

LF PLUG KIT,SIZE 1,9.5MM

2-745492-0

PLUG ASSY,9P,HDE,MS

1-747944-6

KIT,PLUG,9P,HDE,SHLD ENCLSRE

1571650-6

LF PLUG KIT,SIZE 1,10.8MM

1571650-4

LF PLUG KIT,SIZE 1,7.2MM

Show 3 More
