1-5745968-6

The 1-5745968-6 is a 25-position, HD-20 series, front metal-shell, straight posted subminiature D-connector plug with fixed female 4-40 screwlocks. ...

View Datasheet Ask the Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 1-5745968-6 is a 25-position, size 3, AMPLIMITE HD-20 series straight posted plug connector designed for PCB mounting. It features a tin-plated steel front metal-shell, a black 94V-0 rated thermoplastic housing, and is preloaded with size 20 DF posted pin contacts made of brass. The contacts have gold flash plating on the mating end and tin on the termination end over a nickel underplate, and the connector includes fixed female 4-40 screwlocks for secure mating. With a post length of 0.170 inches , it is recommended for PCB thicknesses from 0.093 to 0.125 inches . This RoHS compliant connector provides a reliable interface for various electronic applications requiring a robust D-sub connection to a printed circuit board.

Product Highlights:

  • 25 Positions
  • With Contacts
  • Housing Gender = Plug
  • PCB Mount Angle = Vertical
  • Product Series = HD 20

Search Keywords: 157459686

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-5745968-6
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Package Type:
TUBE
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
Pin
Termination Method:
Solder
Shell Size:
3
Number of Contacts:
25
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C
