1-480287-0

Name: 1-480287-0 Te Connectivity Amp Brand Discrete Wire Housing
Brand: Te Connectivity Amp Brand
SKU: 10183071
Availability: InStock

12P CMNL PLUG HSG M/M NATL ...

View Datasheet

Ask the Datasheet

RoHS Compliant

BAG Packaging

Certificate of Compliance

DESCRIPTION

1-480287-0 is a 12-circuit dual row socket housing (plug) designed for use in Commercial MATE-N-LOK wire-to-board connector systems. This motor mount positive lock housing features UL94V-2 flammability rated nylon material in natural color and accepts double wire applications where individual insulation diameters do not exceed 0.115 inches (2.92 mm). The housing has dimensions of E: 1.290 inches (32.77 mm) and F: 1.195 inches (30.35 mm), with a 0.200 inch (5.08 mm) centerline spacing. It mates with pin housing (cap) part number 1-480288-0 and is compatible with pre-tin duplex plated PC board headers. This RoHS compliant connector is ideal for power circuit applications in home appliances and industrial equipment requiring reliable wire-to-board connections.

Product Highlights:

Housing
Contact Diameter = 2.13 mm
Number of Circuits = 12
4.95 x 9.14 mm Centerline, Matrix
Double-Row Contact Layout

Potential Applications:

Search Keywords: 14802870

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

1-480287-0

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8538906000

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
