1-2371035-1 by te connectivity / amp brand
Image is representational - see mfr. specs

1-2371035-1

TE Connectivity / AMP Brand

The 1-2371035-1 is a 2-position HVA HD400 plug housing for high-voltage cable-to-panel connections in e-mobility applications. ...

Datasheet
RoHS Compliant
Carton Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 1-2371035-1 is a 2-cavity plug housing from the HVA HD400 series, designed for high-voltage connections in harsh environments. It features a 4 mm diameter contact system and is designed for cable-to-panel mounting. This housing supports 2.5 mm², 4.0 mm², and 6.0 mm² cable sizes and operates reliably across a wide temperature range of -40°C to +140°C. The connector system is rated for up to 1000 VDC and 60 A at 80°C. With an IP68 and IP6K9K ingress protection rating and a UL94-V0 flammability rating, it is ideal for demanding e-mobility applications such as e-motors, brake units, and other high-voltage accessories.

Search Keywords: 123710351

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-2371035-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694020
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
154
Package Type:
Carton
Connector & Housing Type:
Housing for female terminals
Primary Product Color:
Orange
Sealable:
Yes
Connector System:
Cable-to-Panel
Cable Exit Angle:
180°
Contact Current Rating (Max):
70 A
Operating Voltage:
1000 VAC, 1000 VDC
Circuit Application:
Power & Signal
Mating Pin Diameter:
1.57 in, 4 mm
Strain Relief:
With
Operating Temperature Range:
-40 – 140 °C, -104 – 284 °F
Degree of Protection:
IPX9K
Connector Position Assurance Capable:
Yes
Terminal Position Assurance:
Yes
Operating Temperature (Max):
140 °C, 284 °F
Number of Positions:
2
Primary Locking Feature:
On the Terminal
Mating Alignment:
With
Mating Alignment Type:
Keyed
Connector Shape:
Circular
Housing Material:
PA GF
Contact Type:
Socket
Contact Size:
1.2mm , 4mm
Connector Mounting Type:
Cable Mount (Free-Hanging)

IN STOCK: 252

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 21 Weeks

Qty
Unit Price
5
$17.44
10
$16.94
25
$16.28
50
$15.78
154
$14.97
308
$11.71
616 +
$9.51
