1-1747820-2

Name: 1-1747820-2
Brand: Te Connectivity Amp Brand
SKU: 44149154
Price: 196.5 USD
Availability: InStock

TE Connectivity / AMP Brand

DYNAMIC D5300 TAB HSG 4P/XX ...

Datasheet

RoHS Compliant

Bag Packaging

Certificate of Compliance Guarantee

DESCRIPTION

1-1747820-2 is a D-5300 reversed installation tab housing connector designed for high-voltage signal and power circuit applications within the DYNAMIC Series family. This connector supports a maximum rating of 630V and 45A per position, making it suitable for both signal-level and power distribution circuits in ruggedized, industrialized packages. The reversed installation design provides flexibility for applications requiring non-standard connector orientation, while maintaining the standardized contact system that minimizes application tooling requirements. The connector is commonly used in industrial control systems, factory automation, motion and drives applications, and variable frequency drives where high-density signal and power connectivity is essential. Its modular capability allows for system expansion as needed, and it complies with UL E28476 and CSA LR7189 safety standards.

Product Highlights:

Potential Applications:

Search Keywords: 117478202

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

1-1747820-2

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536904000

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
