1-1658622-1 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

1-1658622-1

A 60-position, center and military polarized Novo receptacle for terminating .050 inch pitch ribbon cable to a .100 x .100 inch grid. ...

View Datasheet Ask the Datasheet
RoHS Compliant
TRAY Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 1-1658622-1 is a 60-position Novo receptacle connector designed for mass termination of ribbon cable in wire-to-board applications. It features a .100 x .100 inch centerline grid and provides both center and military polarization options. The contacts have Duplex² plating, which includes a minimum of .000030 inches of gold or gold flash over palladium-nickel on the mating end and tin on the termination end, all over a nickel underplate. This preassembled connector utilizes a military-approved tuning fork contact design for reliable interconnection with .025 inch square or round posts, making it ideal for various electronic equipment requiring a robust interconnect solution.

Product Highlights:

  • Connector Type = NOVO
  • 60 Positions
  • Receptacle
  • Mating Polarization Method = Center & Military
  • With Mating Polarization

Search Keywords: 116586221

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-1658622-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694051
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
27
Package Type:
TRAY
Type:
IDC Connector
Body Orientation:
Right Angle
Gender:
RCP
Mounting:
Cable Mount
Pitch:
2.54 mm
Number of Contacts:
60
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
1/Contact A
Termination Method:
IDT
Operating Temperature:
-65 to 105 °C

FREQUENTLY ASKED QUESTIONS

Is 1-1658622-1 RoHS compliant?

Yes, 1-1658622-1 is RoHS compliant.

What is the lead time for 1-1658622-1?

The standard lead time for 1-1658622-1 is approximately 8 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 286

Can Ship immediately

MOQ for In Stock Qty: 27

MOQ for out of Stock Qty: 1350

Multiple: 27

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
27
$4.50
270
$3.90
513
$3.79
1,026
$3.55
1,350
$3.54
2,700
$3.53
4,050
$3.52
5,400 +
$3.51
