1-1469491-3 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

1-1469491-3

The 1-1469491-3 is a right-angle, 90° keyed VITA 46 guide module used for aligning daughter cards in backplane systems. ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 1-1469491-3 is a right-angle VITA 46 guide module designed to ensure proper alignment in board-to-board connections. This die-cast module features 90° keying to prevent the mis-mating of daughter cards and has a silver-plated finish. It is designed for a vertical pin with an 11.6 mm thread depth and offers a gatherability of +/-3.5 mm. Meeting the VITA 46 specification, this RoHS compliant guide module is essential for reliable blind-mating in backplane and co-planar interconnection systems.

Product Highlights:

  • Pin, External Thread
  • Guidance Series
  • VITA 41/VITA 46 Configuration
  • Used With 9mm Guide Module

Search Keywords: 114694913

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-1469491-3
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
7907006000
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
BAG
Type:
Pin External Thread
Dimension:
35.6 x 9 mm
Operating Temperature:
N/A

FREQUENTLY ASKED QUESTIONS

Is 1-1469491-3 RoHS compliant?

Yes, 1-1469491-3 is RoHS compliant.

What is the lead time for 1-1469491-3?

The standard lead time for 1-1469491-3 is approximately 2 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 5,147

Can Ship immediately

Manufacturer Stock: 23,734   can ship 10/12/26

Minimum Order Quantity: 5

Factory Lead-Time 2 Weeks can ship 10/12/26

Price (USD)

Qty
Unit Price
5
$4.40
25
$4.29
100
$4.19
250
$4.13
500
$4.08
1,000
$4.03
2,500 +
$3.98
Log in for special pricing Click for Quote Price Match Request
