111360-1 by te connectivity / amp brand
TE Connectivity / AMP Brand Authorized Distributor

111360-1

Conn Unshrouded Header PL 10 POS 1.27mm Solder ST Top Entry Thru-Hole ...

View Datasheet Ask the Datasheet
RoHS Non-Compliant
Tray Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

111360-1 is a paddleboard connector assembly designed for short-end applications with 0.100 inch long posts and full tin-plated contacts integrated with an AMP-latch mechanism. The assembly features molded nylon or polyester parts rated as flame retardant 94 V-O with glass filling in black color, and phosphor bronze contacts per QQ-B-750 specification. Contact finishes include bright tin-lead plating at 0.0001–0.0002 inch thickness over nickel (0.00005 inch minimum) or bright tin plating at equivalent thickness. The connector incorporates multiple standoff positions arranged in diagonal rows for secure mounting and alignment, with spacing dimensions of 0.050 inch staggered intervals and post dimensions of 0.100±0.010 inch. This assembly is commonly used in electronic interconnect applications requiring reliable contact engagement and mechanical stability.

Search Keywords: 1113601

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
111360-1
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536694040
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
294
Package Type:
Tray
Mounting:
Through Hole
Body Orientation:
Straight
Gender:
PL
Termination Method:
Solder
Number of Contacts:
10
Maximum Voltage Rating:
N/A
Maximum Current Rating:
N/A
Operating Temperature:
N/A

FREQUENTLY ASKED QUESTIONS

Is 111360-1 RoHS compliant?

No, 111360-1 is not RoHS compliant.

What is the lead time for 111360-1?

The standard lead time for 111360-1 is approximately 13 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 445

Can Ship immediately

MOQ for In Stock Qty: 2

MOQ for out of Stock Qty: 2

Factory Lead-Time 13 Weeks

Price (USD)

Qty
Unit Price
2
$20.32
25
$13.12
100
$12.44
221
$12.33
441
$12.20
662
$12.08
882 +
$11.96
Log in for special pricing Click for Quote Price Match Request
