103308-2 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

103308-2

014 LOPRO HDR SP 15DP ...

View Datasheet
RoHS Non-Compliant
TUBE Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

103308-2 is a low-profile double-row header connector designed for manual insertion into printed circuit boards. It features 14 contact positions arranged in a double-row configuration with 0.100 inch (2.54 mm) centerline spacing between rows and positions. The connector has a length of 1.000 inch (25.40 mm) and a width of 0.600 inch (15.24 mm), with a post diameter of 0.035±0.003 inch (0.89±0.08 mm). The housing is constructed from gray thermoplastic rated 94V-0, and the posts are copper alloy with duplex plating. This connector is commonly used in applications requiring reliable interconnection in space-constrained environments, such as instrumentation, data acquisition systems, and general-purpose electronic assemblies where low-profile headers are preferred.

Product Highlights:

  • Connector Type = Pin Headers
  • Low Profile
  • Number of Positions = 14
  • 2.54 x 2.54 mm Centerline, Matrix
  • PCB Mount Angle = Vertical

Search Keywords: 1033082

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
103308-2
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
TUBE
Type:
Shrouded Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
14
Maximum Voltage Rating:
N/A
Maximum Current Rating:
1/Contact A
Termination Method:
Solder
Operating Temperature:
-65 to 105 °C

FREQUENTLY ASKED QUESTIONS

Is 103308-2 RoHS compliant?

No, 103308-2 is not RoHS compliant.

What is the lead time for 103308-2?

The standard lead time for 103308-2 is approximately 8 days. In-stock quantities ship from Master Electronics.

  This product is NOT RoHS Compliant.  See Alternatives

IN STOCK: 604

Can Ship immediately

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
100
$1.291
300
$1.249
500
$1.230
1,000
$1.093
2,500
$1.061
5,000 +
$0.958
Supplier's Standard Package
