TPA11CGRA204 by te connectivity / alcoswitch brand
Image is representational - see manufacturer specifications
TE Connectivity / Alcoswitch Brand Authorized Distributor

TPA11CGRA204

Switch Tactile OFF (ON) SPST Round Plunger PC Pins 20VAC 20VDC 0.4VA 3.92N Thru-Hole Loose Piece ...

View Datasheet
RoHS Compliant
Pack Packaging
Accessories
Request Programming Quote
Discontinued
Certificate of Compliance

DESCRIPTION

The TPA11CGRA204 is a mechanical tactile pushbutton switch from the TPA series designed for surface-mount printed circuit board applications. It features a single pole-single throw (SPST) configuration with a contact rating of 0.4VA and gold-plated copper alloy contacts for reliable electrical performance. The switch employs a right-angle mount orientation with an extended round red nylon actuator measuring 3.84 mm in length, housed in a thermoplastic LCP case body. It is rated for through-hole mounting with printed circuit board termination and operates across a standard industrial temperature range. This switch is commonly used in consumer electronics, industrial control panels, and portable devices where compact tactile feedback and low-power switching are required.

Product Highlights:

  • Switch - Mechanical
  • Tactile
  • Single Pole - Single Throw Configuration (Pole-Throw)
  • Contact Rating = 0.4VA
  • Operating Function = Off [On]

Search Keywords: TPA11CGRA204

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Alcoswitch Brand
Part No:
TPA11CGRA204
Alias/AKA:
1825096-5
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509031
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Pack
Dimension:
8.13 x 12.9 x 5.74 mm
Mounting:
PCB Through Hole
Pole Throw Configuration:
SPST
Switch Configuration:
Off (On)
Actuator Style:
Round Plunger
Operating Force:
3.92 N
Contact Rating @ Voltage:
0.4@20VAC 20VDC A
Illumination Type:
N/R
Body Orientation:
Right Angle
Termination Style:
PC Pins
Seal Location:
N/R
Life Cycle:
Discontinued

FREQUENTLY ASKED QUESTIONS

Is TPA11CGRA204 discontinued?

Yes, TPA11CGRA204 from Te Connectivity / Alcoswitch Brand is discontinued (end-of-life September 2026). Master Electronics is an authorized distributor and may have remaining stock or a recommended replacement for it.

Is TPA11CGRA204 RoHS compliant?

Yes, TPA11CGRA204 is RoHS compliant.

What is the lead time for TPA11CGRA204?

The standard lead time for TPA11CGRA204 is approximately 36 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 0

On Order: 925   can ship 11/12/26

MOQ for In Stock Qty: 25

MOQ for out of Stock Qty: 250

Multiple: 25
