GDH02STR04 by te connectivity / alcoswitch brand
Image is representational - see mfr. specs

GDH02STR04

TE Connectivity / Alcoswitch Brand

Switch DIP ON OFF SPST 2 Recessed Rocker 0.025A 24VDC Gull Wing 1.27mm SMD T/R ...

Datasheet
RoHS Compliant
Reel Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / Alcoswitch Brand part GDH02STR04 is a compact and versatile DIP switch. With a single-pole, single-throw (SPST) configuration, it offers an easy and convenient solution for ON/OFF control applications. Featuring a recessed rocker design, this switch promotes a secure and protected operation. It has a low-rated current of 0.025A and can handle up to 24VDC of power. With a gull wing configuration and a pitch of 1.27mm, it is suitable for surface mount technology (SMD) applications. This switch is available in tape and reel packaging for efficient and reliable integration into your electronic devices.

Product Highlights:

  • DIP Switch
  • PCB Mount Style = Surface Mount
  • Single Pole - Single Throw Configuration (Pole-Throw)
  • Actuator Style = Recessed Rocker
  • Sealed

Search Keywords: GDH02STR04

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Alcoswitch Brand
Part No:
GDH02STR04
Alias/AKA:
1571983-3
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
CN
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
2000
Package Type:
Reel
Body Orientation:
Straight
Actuator Style:
Recessed Rocker
Actuator Length:
0 mm
Number of Positions:
2
Pole Throw Configuration:
SPST
Mounting:
Surface Mount
Terminal Type:
Gull Wing
Contact Rating @ Voltage:
0.025@24VDC A
Contact Plating:
Gold/Nickel
Terminal Pitch:
1.27 mm

IN STOCK: 31,019

Can Ship immediately

Minimum Order Quantity: 250

Factory Lead-Time 21 Weeks

Qty
Unit Price
250
$1.13
500
$1.10
2,000
$1.09
4,000 +
$1.04
Reel Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
