FSMRA7JH04 by te connectivity / alcoswitch brand
Image is representational - see manufacturer specifications
TE Connectivity / Alcoswitch Brand Authorized Distributor

FSMRA7JH04

Switch Tactile OFF (ON) SPST Round Button PC Pins 0.05A 24VDC 1.57N Thru-Hole Loose Piece ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The TE Connectivity / Alcoswitch Brand part FSMRA7JH04 is a tactile switch with an OFF (ON) action. It features a single-pole, single-throw (SPST) configuration and is designed with a round button. With PC pins for easy circuit board mounting, this switch has a maximum rating of 0.05A and 24VDC. It provides a tactile feedback of 1.57N and is designed for through-hole installation. This particular variant is sold as a loose piece, offering flexibility in ordering quantities.

Search Keywords: FSMRA7JH04

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Alcoswitch Brand
Part No:
FSMRA7JH04
Alias/AKA:
2-1825027-0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509031
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
BAG
Dimension:
8.41 x 10 x 7.01 mm
Mounting:
PCB Through Hole
Pole Throw Configuration:
SPST
Switch Configuration:
Off (On)
Actuator Style:
Round Button
Operating Force:
1.57 N
Contact Rating @ Voltage:
0.05@24VDC A
Illumination Type:
N/R
Body Orientation:
Right Angle
Termination Style:
PC Pins
Seal Location:
N/A

FREQUENTLY ASKED QUESTIONS

Is FSMRA7JH04 RoHS compliant?

Yes, FSMRA7JH04 is RoHS compliant.

What is the lead time for FSMRA7JH04?

The standard lead time for FSMRA7JH04 is approximately 16 days. In-stock quantities ship from Master Electronics.

IN STOCK: 245,073

Can Ship immediately

Minimum Order Quantity: 1000

Multiple: 1000

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
1
$0.1053
1,000
$0.0957
3,000
$0.0946
5,000
$0.0944
8,000
$0.0937
25,000
$0.0935
50,000
$0.0932
100,000
$0.0930
150,000 +
$0.0928
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
