A101SYZQ04 by te connectivity / alcoswitch brand

A101SYZQ04

TE Connectivity / Alcoswitch Brand

Switch Toggle ON None ON SPDT Long Bat Lever Wire Lug 5A 250VAC 30VDC Panel Mount with Threads ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The A101SYZQ04 is a versatile and reliable toggle switch from TE Connectivity's Alcoswitch brand. This SPDT (Single Pole Double Throw) switch is designed with a long bat lever for easy operation and a wire lug for secure connections. It has a rating of 5A at 250VAC and 30VDC, making it suitable for a wide range of applications. The panel mount design with threads ensures a secure and stable installation. With its high-quality construction and dependable performance, the A101SYZQ04 is an excellent choice for any electrical project.

Search Keywords: A101SYZQ04

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Alcoswitch Brand
Part No:
A101SYZQ04
Alias/AKA:
4-1825136-9
RoHS:
Yes
HTS:
8536509065
COO:
CN
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
Bag
Pole Throw Configuration:
1P2T (SPDT)
Switch Configuration:
On None On
Contact Rating @ Voltage:
5@125VAC A
Actuator Style:
Long Bat Lever
Mounting:
Panel Mount with Threads
Thread Size:
1/4-40
Body Orientation:
Straight
Terminal Type:
Solder
Dimension:
12.7 x 7.98 x 30.55 mm
Operating Temperature:
-20 to 85 °C

IN STOCK: 10

Can Ship immediately

On Order: 2,000   can ship 1/19/26

Minimum Order: 10

Factory Lead-Time 15 Weeks

Qty
Unit Price
10
$3.74
50
$3.02
300
$2.71
500
$2.56
1,000
$2.54
2,500
$2.53
5,000
$2.52
7,500 +
$2.51
