7022PA by te connectivity / agastat brand
Image is representational - see manufacturer specifications
TE Connectivity / Agastat Brand Authorized Distributor

7022PA

Industrial Electropneumatic Timing Relay - 2FormC - DPDT - .1 to 1 sec Off Delay - 125VDC ...

View Datasheet
RoHS Non-Compliant
BAG Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The TE Connectivity / Agastat Brand part 7022PA is a reliable and efficient Industrial Electropneumatic Timing Relay. Featuring a 2FormC, DPDT configuration, this relay provides excellent versatility and compatibility for various applications. With a precise Off Delay timing range of .1 to 1 second and a voltage rating of 125VDC, it ensures optimal performance and accuracy in controlling processes and functions. Trust in the TE Connectivity / Agastat Brand 7022PA for high-quality timing relay solutions in industrial settings.

Product Highlights:

  • 7000 Electropneumatic Timing Series
  • Time Delay Relay
  • Input Voltage = 125 VDC
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Rating = 10A @ 240 VAC

Search Keywords: 7022PA

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Agastat Brand
Part No:
7022PA
Alias/AKA:
1-1423164-7
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536410050
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
BAG
Mounting:
Panel Mount
Type:
Time Delay Relay
Contact Arrangement:
DPDT
DC Coil Voltage:
125 V
AC Coil Voltage:
N/A
Contact Form:
2 Form C
Maximum Current Rating:
10 A
Termination Style:
Screw Terminal
Time Range:
0.1 to 1 sec

FREQUENTLY ASKED QUESTIONS

Is 7022PA RoHS compliant?

No, 7022PA is not RoHS compliant.

What is the lead time for 7022PA?

The standard lead time for 7022PA is approximately 29 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 11

Can Ship immediately

MOQ for out of Stock Qty: 2

Factory Lead-Time 29 Weeks

Price (USD)

Qty
Unit Price
1
$850.39
2
$846.24
4
$844.13
6
$842.02
8 +
$799.64
Log in for special pricing Click for Quote Price Match Request
