7022AE by te connectivity / agastat brand

7022AE

TE Connectivity / Agastat Brand

Time Delay Relay - DPDT (2 Form C) - Off-Delay - 20 Sec to 200 Sec - 10A @ 240VAC - 120VAC Supply - Hand Dial - Screw Terminal. ...

Datasheet
RoHS Non-Compliant
Pack Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TE Connectivity / Agastat Brand part 7022AE is an efficient and reliable industrial electropneumatic timing relay. With a 2FormC DPDT configuration, it offers reliable control and switching capabilities. This specific model has an off delay timing function that can be set from 20 to 200 seconds. It operates on input voltages of 120VAC 60 Hz or 110VAC 50 Hz, making it suitable for various industrial applications. Trust the TE Connectivity / Agastat Brand 7022AE timing relay to provide accurate and precise timing control in your electrical systems.

Product Highlights:

  • 7000 Electropneumatic Timing Series
  • Time Delay Relay
  • Input Voltage = 110 VAC, 120 VAC
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Rating = 10A @ 240 VAC

Search Keywords: 7022AE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Agastat Brand
Part No:
7022AE
Alias/AKA:
1423162-9
RoHS:
No
HTS:
8536410050
COO:
US
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Mounting:
Panel Mount
Type:
Time Delay Relay
Contact Arrangement:
DPDT
DC Coil Voltage:
N/A
AC Coil Voltage:
115 V
Contact Form:
2 Form C
Maximum Current Rating:
10 A
Termination Style:
Screw Terminal
Time Range:
20 to 200 sec

IN STOCK: 3

Ships today, if you order in

On Order: 10   can ship 7/15/26

Factory Lead-Time 52 Weeks

Qty
Unit Price
1
$616.40
3
$613.32
5 +
$597.29
