SPECIFICATIONS
Supplier:
TE Connectivity / ABB Entrelec
Unit of Measure:
Per Each
Supplier Standard Pack
: 50
Current Rating (CSA):
20 A
Storage Temperature Range:
-55 – 110 °C, -67 – 230 °F
Main Circuit Capacity - 1 Rigid Conductor per Spring Clamp:
26 – 12 AWG, .2 – 4 mm²
Product Weight:
5.5 g, .217 oz
Main Circuit Capacity - Twin Ferrule per Spring Clamp:
26 – 20 AWG, .22 – .5 mm²
Voltage Rating (IEC):
1000 V
Operating Voltage Rating (UL & CSA) (Max) - Main Circuit:
600 V
Operating Temperature Range:
-55 – 110 °C, -67 – 230 °F
DIN Rail Mounting Type:
TH35-15 , TH35-7.5
Block Configuration:
Feed-Through
Current Rating (IEC):
24 A
Tool Size:
.138 in, 3.5 mm
Wire Stripping Length:
.433 in, 11 mm
Impulse Withstanding Voltage Rating (IEC):
8000 V
Installation Temperature Range:
-5 – 40 °C, 23 – 104 °F
Connector Mounting Type:
DIN Rail
Current Rating (UL):
20 A
Voltage Rating (CSA):
600 V
Short-Time Withstanding Current Rating @ 1s:
300 A
Modular Terminal Block Product Type:
PI-Spring Terminal Block
Rated Cross Section:
12 AWG, 2.5 mm²
UL Flammability Rating:
UL 94V-0
Gauge Type:
A2 / 2.3 mm Dia.
Main Circuit Capacity - 1 Insulated Ferrule per Spring Clamp:
26 – 14 AWG, .22 – 2.5 mm²
Dielectric Test Voltage:
2200 V
Housing Material:
Polyamide
Product Spacing:
.205 in, 5.2 mm
IN STOCK:
Ships today, if you order in
BONDED Quantity:
0
Manufacturer Stock:
0
can ship
Stock lot only:
Minimum Order Quantity:
50
MOQ for out of Stock Qty:
Multiple:
50
Factory Lead-Time
2 Weeks
can ship
8/28/26
This product is no longer being manufactured but there may be alternatives. We can help you, Contact Us .
