1SNK506152R0000 by te connectivity / abb entrelec
Image is representational - see mfr. specs

1SNK506152R0000

TE Connectivity / ABB Entrelec

ZS6-4S-PE

Datasheet
RoHS Compliant
Box Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

ZS6-4S-PE

Search Keywords: 1SNK506152R0000

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / ABB Entrelec
Part No:
1SNK506152R0000
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
FR
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Box
Impulse Withstanding Voltage Rating (IEC):
8000 V
Rated Cross Section:
10 AWG, 4 mm²
Product Weight:
19.4 g, .764 oz
Product Depth:
48.3 mm
Main Circuit Capacity - 1 Rigid Conductor per Screw Clamp:
24 – 10 AWG, .2 – 6 mm²
Main Circuit Capacity - Twin Ferrule per Screw Clamp:
24 – 14 AWG, .22 – 2.5 mm²
Product Length:
48.3 mm
UL Flammability Rating:
UL 94V-0
Installation Temperature Range:
-5 – 40 °C, 23 – 104 °F
Dielectric Test Voltage:
2000 V
IP Rating:
IP20
Modular Terminal Block Product Type:
Screw Clamp Terminal Block
Tool Size:
.157 in, 4 mm
Number of Circuits:
1
Short-Time Withstanding Current Rating @ 1s:
480 A
Product Height:
79.2 mm
Main Circuit Capacity - 2 Rigid Conductors per Screw Clamp:
24 – 14 AWG, .2 – 2.5 mm²
Product Spacing:
.236 in, 6 mm
Housing Material:
Polyamide
Number of Levels:
1
Connector Mounting Type:
DIN Rail
Gauge Type:
A4-B3
Wire Stripping Length:
.413 in, 10.5 mm
Block Configuration:
Ground
Number of Positions:
4
Main Circuit Capacity - 1 Insulated Ferrule per Screw Clamp:
24 – 12 AWG, .22 – 4 mm²
Storage Temperature Range:
-55 – 110 °C, -67 – 230 °F
Main Circuit Capacity - 1 Flexible Conductor per Screw Clamp:
.22 – 6 mm²
Operating Temperature Range:
-55 – 110 °C, -67 – 230 °F
DIN Rail Mounting Type:
TH35-15 , TH35-7.5
Primary Product Color:
Green & Yellow

IN STOCK: 0

On Order: 200   can ship 1/6/27

Minimum Order Quantity: 25

Multiple: 25

Factory Lead-Time 47 Weeks

Qty
Unit Price
25
$11.48
50
$10.03
100
$9.16
250
$8.24
500
$7.88
1,000
$7.60
2,500 +
$7.59
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Product Changes
