RAPC712X by switchcraft
Image is representational - see mfr. specs

RAPC712X

Switchcraft

DC Power Connector - Jack - 5 A - 2.5 mm - PCB Mount - Through Hole. ...

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The SWITCHCRAFT RAPC712X is a high-quality DC power connector designed for use on printed circuit boards. It features a jack-style design, allowing for easy connection of power cables. With a current rating of 5 A, this connector is capable of handling moderate power requirements. The 2.5 mm diameter ensures compatibility with a wide range of power cables. The PCB mount and through-hole installation method provide secure and stable mounting on your circuit board. This power connector is a reliable and efficient solution for your DC power needs.

Search Keywords: RAPC712X

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Switchcraft
Part No:
RAPC712X
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694020
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
Power
Body Orientation:
Right Angle
Mounting:
Through Hole
Gender:
PL
Number of Contacts:
2
Termination Method:
Solder
Maximum Voltage Rating:
N/A
Maximum Current Rating:
5 A
Operating Temperature:
N/A

IN STOCK: 0

On Order: 8,320   can ship 5/6/26

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 10 Weeks

Qty
Unit Price
100
$1.114
300
$1.054
500
$1.024
1,000
$1.019
2,500
$1.014
5,000
$1.009
7,500
$1.004
10,000 +
$0.999
Suppliers Standard Package
