12CL5MX by switchcraft
Image is representational - see manufacturer specifications
Switchcraft Authorized Distributor

12CL5MX

DIN Audio / Video Connector - 5 Contacts - Plug - Cable Mount - Solder - Tin Plated Contacts - Metal Body. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 12CL5MX is a 5-conductor Cable-mount DIN Male Plug with ground key-rib. Unique 30° turn locking securely fastens two halves of the connector. It mates with lock flange female connectors and receptacles. Insert screw holds insert assembly in shell and also retains locking on shell. The flexible black strain relief with 7/32-inch diameter cable entry. It is made up of nickel-plated die-cast zinc alloy shell, steel receptacle mounting flange receptacle plastic body and insert, silver-plated switching contacts and soft plastic cable relief bushing.

Search Keywords: 12CL5MX

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Switchcraft
Part No:
12CL5MX
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694020
COO:
TW
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
80
Body Orientation:
Straight

FREQUENTLY ASKED QUESTIONS

Is 12CL5MX RoHS compliant?

Yes, 12CL5MX is RoHS compliant.

What is the lead time for 12CL5MX?

The standard lead time for 12CL5MX is approximately 14 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 785

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
5
$16.71
10
$13.52
25
$12.57
80
$11.92
160
$11.58
320
$11.55
560 +
$10.48
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request
