PF380D25 by sensata / crydom
Image is representational - see manufacturer specifications
Sensata / Crydom Authorized Distributor

PF380D25

Solid State Relay - SPST-NO (1 Form A) - AC, Zero Cross Output - 4 to 15VDC Input - 25A, 48 to 530V - 4-SIP Package - PC Pin Termination. ...

View Datasheet
RoHS Compliant
EACH Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The PF380D25 from Crydom is single pole single throw SPST (1 Form A) solid state relay with NO contact configuration and PC pin termination. This relay has AC, Zero Cross output and 25A, 48 to 530V load ratings. Operates at input voltage range from 4 to 15VDC. Dimensions of this relay are: 1.6" (38.1mm) x 1.35" (34.3mm).

Search Keywords: PF380D25

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Sensata / Crydom
Part No:
PF380D25
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490080
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
EACH
Output Type:
AC
Maximum Output Voltage:
530(RMS) V
Maximum Output Current:
25(RMS) A
Output Device:
SCR
Input Type:
DC
Input Voltage:
15 V
Mounting:
Through Hole
Circuit Arrangement:
1 Form A
Dimension:
43.1 x 22.8 x 34.3(Max) mm

FREQUENTLY ASKED QUESTIONS

Is PF380D25 RoHS compliant?

Yes, PF380D25 is RoHS compliant.

What is the lead time for PF380D25?

The standard lead time for PF380D25 is approximately 10 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 100

Ships today, if you order in

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
1
$62.13
5
$43.86
20
$39.94
40
$38.12
60
$37.59
100
$36.56
260 +
$36.06
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request
