F1857SDK1200 by sensata / crydom
Sensata / Crydom Authorized Distributor

F1857SDK1200

SCR/Diode Power Module - Load Current: 55A - Circuit Type: SDK - Operating Voltage 480VAC - Chassis Mount

View Datasheet
RoHS Compliant
EACH Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The F1857SDK1200 is a Series F18 power module. Maximum DC output current is 55A at 85°C, repetitive peak reverse voltage is 480VAC. Isolation voltage is 2500Vrms. Operating temperature range is -40°C .. +125°C.

Search Keywords: F1857SDK1200

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Sensata / Crydom
Part No:
F1857SDK1200
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8541300080
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
80
Package Type:
EACH
Maximum Gate Trigger Voltage:
3 V
Maximum Gate Trigger Current:
150 mA
Mounting:
Screw
Pin Count:
7
Dimension:
91.9 x 20 x 29.9 mm
Packaging:
N/A
Peak On-State Voltage:
N/A
Maximum Gate Peak Inverse Voltage:
5 V
Family:
F1857SDK1200
Operating Temperature:
-40 to 125 °C

FREQUENTLY ASKED QUESTIONS

Is F1857SDK1200 RoHS compliant?

Yes, F1857SDK1200 is RoHS compliant.

What is the lead time for F1857SDK1200?

The standard lead time for F1857SDK1200 is approximately 16 days. In-stock quantities ship from Master Electronics.

IN STOCK: 0

MOQ for out of Stock Qty: 20

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
20
$449.06
40
$237.01
60
$162.99
80 +
$159.73
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request
