CSW2450-10
CSW2450-10
In Stock: 23
Minimum Order: 3
VIEW PRODUCT
D2450-10 by sensata / crydom
Image is representational - see manufacturer specifications
Sensata / Crydom Authorized Distributor

D2450-10

Solid-State Relay - Control Voltage 3-32 VDC - Max Input Current 12 mA - Output 24-280 VAC - Max Load Current 50 A - 4 Pins - 1 Form A - Screw Termination ...

View Datasheet Ask the Datasheet
RoHS Compliant
EACH Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The D2450-10 is a solid-state relay series 1 with SCR output for heavy industrial loads. Input control voltage range is 3-32 VDC. Operating voltage is 24-280 VAC and the max load current is 50 A. Series 1 relay has redesigned housing with anti-rotation barriers. I/O isolation voltage is 4000 Vrms. Switching type: instantaneous turn-on. Mounting type: panel mount.

Search Keywords: D245010

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Sensata / Crydom
Part No:
D2450-10
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490080
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
EACH
Output Type:
AC
Maximum Output Voltage:
280(RMS) V
Maximum Output Current:
50(RMS) A
Output Device:
SCR
Input Type:
DC
Input Voltage:
32 V
Mounting:
Screw
Circuit Arrangement:
N/A
Dimension:
58.4 x 45.7 x 23 mm

FREQUENTLY ASKED QUESTIONS

What replaces D2450-10?

The recommended replacement for D2450-10 is CSW2450-10 from Sensata / Crydom, available from Master Electronics.

Is D2450-10 RoHS compliant?

Yes, D2450-10 is RoHS compliant.

What is the lead time for D2450-10?

The standard lead time for D2450-10 is approximately 8 days. In-stock quantities ship from Master Electronics.
