ALTERNATIVE PRODUCTS
Older Equivalent
CSW2425K
CSW2425K
In Stock: 111
Minimum Order: 2
VIEW PRODUCT
D2425K by sensata / crydom
Image is representational - see manufacturer specifications
Sensata / Crydom Authorized Distributor

D2425K

Solid-State Relay - Control Voltage 3-32 VDC - Max Input Current 12 mA - Output 24-280 VAC - Max Load Current 25 A - 4 Pins - 1 Form A -Hex Standoffs Termination ...

View Datasheet Ask the Datasheet
RoHS Compliant
EACH Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The D2425K is a solid-state relay series 1 with SCR output for heavy industrial loads. Input control voltage range is 3-32 VDC. Operating voltage is 24-280 VAC and the max load current is 25 A. Series 1 relay has redesigned housing with anti-rotation barriers. I/O isolation voltage is 4000 Vrms. Switching type: zero voltage turn-on. Mounting type: panel mount.

Search Keywords: D2425K

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Sensata / Crydom
Part No:
D2425K
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490080
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
EACH
Output Type:
AC
Maximum Output Voltage:
280 V
Maximum Output Current:
25 A
Output Device:
Triac
Input Type:
DC
Input Voltage:
32 V
Mounting:
Screw
Circuit Arrangement:
N/A
Dimension:
57.3 x 44.5 x 22.6 mm

FREQUENTLY ASKED QUESTIONS

What replaces D2425K?

The recommended replacement for D2425K is CSW2425K from Sensata / Crydom, available from Master Electronics.

Is D2425K RoHS compliant?

Yes, D2425K is RoHS compliant.

What is the lead time for D2425K?

The standard lead time for D2425K is approximately 10 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 60

Can Ship immediately

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
1
$57.03
5
$56.37
20
$54.60
40
$53.48
60
$52.72
100
$52.01
260 +
$51.17
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request
