D2425D by sensata / crydom
Image is representational - see manufacturer specifications
Sensata / Crydom Authorized Distributor

D2425D

Independently Controlled Dual Output Solid-State Relay - Control Voltage 4-15 VDC - Typical Input Current 13mA/5VDC - Output 24-280 VAC - Max Load Current 25 A ...

View Datasheet Ask the Datasheet
RoHS Compliant
EACH Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The D2425D is an independently controlled dual output solid-state relay with SCR output for heavy industrial loads. Input control voltage range is 4-15 VDC. Operating voltage is 24-280 VAC and the max load current is 25 A. I/O isolation voltage is 4000 Vrms. Switching mode: zero voltage turn-on. Mounting type: panel mount.

Search Keywords: D2425D

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Sensata / Crydom
Part No:
D2425D
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490080
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Package Type:
EACH
Output Type:
AC
Maximum Output Voltage:
280 V
Maximum Output Current:
25 A
Output Device:
SCR
Input Type:
DC
Input Voltage:
4 - 15 V
Mounting:
Screw
Circuit Arrangement:
1 Form A
Dimension:
45.7 x 58.4 x 21.6 mm

FREQUENTLY ASKED QUESTIONS

Is D2425D RoHS compliant?

Yes, D2425D is RoHS compliant.

What is the lead time for D2425D?

The standard lead time for D2425D is approximately 10 days. In-stock quantities ship from Master Electronics.

IN STOCK: 263

Can Ship immediately

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
1
$118.27
5
$116.33
10
$109.98
20
$107.08
50
$103.15
100 +
$102.14
Supplier's Standard Package
