PR13-2-.500A-9642-1-V by sensata / airpax
Image is representational - see manufacturer specifications
Sensata / AIRPAX Authorized Distributor

PR13-2-.500A-9642-1-V

SNAPAK® series is a snap-acting hydraulic magnetic circuit protector, Push to reset. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The PR13-2-.500A-9642-1-V is a two-pole push-to-reset hydraulic-magnetic circuit protector from the SNAPAK® series, combining power switching and circuit protection in a single compact unit. This device features a paddle handle actuator with 15° toggle action, rated for 0.500A continuous current, and is designed for reliable snap-acting protection with accurate trip characteristics. The unit incorporates a two-pole configuration suitable for single-phase AC or DC applications, with mounting provisions for standard panel cutout installation. Key dimensional specifications include a body length of approximately 1.715 inches (43.56 mm) and a mounting depth of 0.500 inches (12.7 mm), enabling integration into space-constrained applications. The push-to-reset mechanism ensures manual control and safe operation, making it ideal for aerospace, industrial control, and power distribution systems requiring dependable overcurrent protection.

Search Keywords: PR132500A96421V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Sensata / AIRPAX
Part No:
PR13-2-.500A-9642-1-V
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536200020
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
3

FREQUENTLY ASKED QUESTIONS

Is PR13-2-.500A-9642-1-V RoHS compliant?

Yes, PR13-2-.500A-9642-1-V is RoHS compliant.

What is the lead time for PR13-2-.500A-9642-1-V?

The standard lead time for PR13-2-.500A-9642-1-V is approximately 12 days. In-stock quantities ship from Master Electronics.

IN STOCK: 25

Ships today, if you order in

Minimum Order Quantity: 3

Multiple: 3

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
3
$40.78
6
$35.98
12
$33.98
27
$33.24
51
$32.19
102
$30.58
252 +
$28.38
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request
