66L060 by sensata / airpax
Image is representational - see manufacturer specifications
Sensata / AIRPAX Authorized Distributor

66L060

Bimetal Disc Thermostat Automotive - 8 lead Mini-DIP package w/4 leads ...

View Datasheet
RoHS Compliant
Tube Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

66L060 is a subminiature bimetallic disc thermostat in an 8-pin DIP package designed for accurate and reliable temperature sensing and switching on printed circuit boards. This single pole/single throw device features open on rise (limit) operation with a factory-preset operating temperature of 60°C (±5°C tolerance), gold-plated contacts, and positive snap action. The thermostat offers contact ratings up to 1A at 120VAC or 48VDC with up to 30,000 life cycles, and achieves 100,000 cycles at low-level gold contact switching. It is sealed with high-temperature epoxy to withstand wave soldering and board washing operations. Common applications include computers, computer peripherals, aircraft, automotive, and test equipment for thermal protection and alarm functions.

Search Keywords: 66L060

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Sensata / AIRPAX
Part No:
66L060
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
903210009
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
Tube
Close Temperature (Celsius):
40 °C
Close Temperature (Fahrenheit):
104 °F
Maximum Current Rating:
1 A
Maximum AC Voltage Rating:
120 V
Maximum DC Voltage Rating:
48 V
Mounting:
PCB Through Hole
Pole Throw Configuration:
SPST
Switch Configuration:
N.C.
Operating Temperature:
40°C to 130 °C
Set Point Function:
Open on Rise
Open Temperature (Celsius):
60 °C
Open Temperature (Fahrenheit):
140 °F

FREQUENTLY ASKED QUESTIONS

Is 66L060 RoHS compliant?

Yes, 66L060 is RoHS compliant.

What is the lead time for 66L060?

The standard lead time for 66L060 is approximately 9 days. In-stock quantities ship from Master Electronics.

IN STOCK: 924

Ships today, if you order in

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 25

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
5
$21.73
10
$17.39
25
$15.34
50
$14.49
75
$14.17
100 +
$12.46
Supplier's Standard Package
