782XBXC-240A

Power relay - SE Relays - 15A - DPDT - 240 VAC - clear cover ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Discontinued & Replaced
Certificate of Compliance

DESCRIPTION

The Magnecraft / Schneider Electric 782XBXC-240A is an electromechanical relay designed for various power applications. This plug-in power relay operates at 240VAC, providing efficient performance and reliable functionality. With a resistance of 15.7KOhm, it ensures proper electrical flow in your circuit. This DPDT (Double Pole, Double Throw) relay can handle a maximum current of 12ADC/15AAC, allowing for smooth switching between circuits. The compact dimensions of 27.9x21mm make it suitable for space-constrained installations. Trust the Magnecraft / Schneider Electric 782XBXC-240A for dependable and efficient power relay operation.

Search Keywords: 782XBXC240A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Schneider Electric-Legacy Relays
Part No:
782XBXC-240A
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490075
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Relay Construction:
Non-Latching
AC Coil Voltage:
240 V
DC Coil Voltage:
N/A
Contact Arrangement:
DPDT
Maximum Current Rating:
10 A
Mounting:
Connector
Termination Style:
Quick Connect
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 70 °C
Coil Resistance:
15.7 KOhm
Life Cycle:
Discontinued & Replaced
